Eclipse One‑Hand Bar Clamp Heavy‑Duty, 600mm 24inch
Price range: R844.00 through R877.00 (each excl. VAT)
Eclipse One‑Hand Bar Clamp Heavy‑Duty, 600mm 24inch clamp/spreader with aluminium body, carbon‑steel bar for up to 300 kgf clamping force…
| Qty | Unit Price (each excl. VAT) | You Save |
|---|---|---|
| 1+ | R 877.00 | |
| 6+ | R 844.00 | less 3.9% |
Eclipse One‑Hand Bar Clamp Heavy‑Duty, 600mm 24inch, (NTEOHBC24-HD)
Eclipse One‑Hand Bar Clamp Heavy‑Duty, 600mm 24inch, (NTEOHBC24-HD) clamp and spreader designed for powerful yet controlled one‑hand operation on heavy‑duty work‑holding tasks. Its lightweight aluminium body and carbon steel bar can deliver up to 300 kgf of sustained clamping force, making it suitable for demanding woodworking, installation and demolition work.
Like other Eclipse heavy‑duty one‑hand clamps, it features an ergonomic pistol‑grip handle, a spring‑loaded insert trigger for quick positioning, and a push‑button system that converts the tool from clamp to spreader in seconds. Removable, non‑marring pads provide an even distribution of pressure while helping to protect finished surfaces from marking.
| Minimum Order Quantities | 1+, 6+ |
|---|
Specifications
- Model: NTEOHBC24‑HD / EOHBC24‑HD heavy‑duty one‑handed bar clamp and spreader
- Clamping capacity: 600 mm (24 inch)
- Minimum spreading capacity: 168 mm (6 5/8 inch)
- Maximum spreading capacity: approximately 800 mm (around 31 1/2 inch), depending on spec sheet
- Maximum clamping force: Up to 300 kgf sustained holding force (heavy‑duty OHB series)
- Throat depth: 85 mm (3 3/8 inch)
- Body/frame material: Lightweight aluminium body for high strength with reduced weight
- Bar material: Carbon steel bar for rigidity and durability
- Handle: Ergonomically designed soft‑feel pistol‑grip handle for comfortable one‑hand operation
- Mechanisms:
- Insert trigger to prevent accidental release and aid quick positioning
- Easy push‑button system for rapid conversion between clamping and spreading modes
- Jaw pads: Removable, non‑marring pads that stay fixed to the clamp, distributing force evenly and helping to protect workpieces from marking
- Typical applications: Heavy‑duty work‑holding in woodworking, cabinetry, installation, demolition, gluing, drilling, sawing and other workshop clamping and spreading tasks
Benefits
- Large 600 mm clamping capacity and up to 300 kgf holding force make this clamp ideal for heavy‑duty work‑holding on wide panels, frames and assemblies.
- Aluminium body and carbon steel bar offer a strong yet relatively lightweight tool, improving handling and reducing user fatigue.
- One‑handed pistol‑grip operation with insert trigger and quick release allows fast positioning and clamping while your other hand remains free to align workpieces.
- Quick clamp‑to‑spreader conversion and non‑marring pads provide versatile clamping and spreading capability while helping to protect finished surfaces from damage.
